BYZD-600B1 (Two Servo) Stand Up Pouch and Three-Side Seal Automatic Pouch Making Machine
USAGE: The machine is designed based on model BYZD-600. In spite of making three side seal pouch, it can also make stand up pouch.
| Technical Datas |
| Bagging Speed |
3 side sealing pouch Max: 150parts/Min
Normal Stand up pouch Max: 100parts/min (According To Material & Operating) |
Production Lane |
1-4 lanes 3-side seal pouches
2 lines normal stand up pouch |
| Film Size Range |
W=1200mm,Max:diameter 600mm |
| Pouch Size Range |
W=50mm-600mm L=60-300mm (L>300mm,working by multiplied feeding) |
| Unwinding Unit |
| Main Web shaft |
Air shaft |
| Main Web Stand |
Half Folded Station |
| Main Web Brake |
Magnetic Brake (Mitsubishi Clutch Brake) |
| L. P. C |
Electric Vision Controller (photoelectric sensor) |
| Main Body |
| Horizontal Heating Unit |
3 Units (L=640mm W=90mm) |
| Horizontal Cooling Unit |
2 Units (L=640mm W=80mm) |
| Vertical Heating Unit |
5 Units (L=640mm W=60mm) |
| Vertical Cooling Unit |
5 Units (L=510mm W=60mm) |
| Control System |
Computer Control |
| Table Conveyor |
Motor control |
| Temperature Control |
16 PCs |
| Cutter |
1set, Seal Bar (Horizontal /Vertical): 11pcs. Tools: 1set |
| Thermocouple |
Attaching Type |
| *with the development of management and technology , the datas will change without notice. |
|
